Products Profile

Plstic Film Greenhouse: It's a kind of multi-span film greenhouse for growing vegetables or flowers. It has following features comparing with other kinds of greenhouse: Less structure use will reduce the structure shadow and provide more even sunlight for the plants.
● Lower cost than PC and GLASS greenhouses.
● Better at heat preservation in certain regions.
● We can provide various specifications in terms of span size, bay size, gutter height and roof height.
● All the systems from cooling system, irrigation system, computer control system and ventilation system, etc. can be provided. We can provide you a turnkey project.
● For installations, we have professional technicians abroad for guidance.
Covering material: 0.15 or 0.2mm plastic film; single layer film; double layer film; inflated double layer film
Frame Work: Double side hot galvanized steel structure
General Size:
● Span Length: 8m, 9.6m
● Bay Size: 4m
● Gutter Height: 3m-4m

Greenhouse System

Roof vent greenhouse can be used with the greenhouse systems we offer, such as ventilation system, Cooling System, irrigation systems, fertilization systems, etc., to achieve high yields.

Inside Shading System

The inner shading/keeping warm system can improve the ecological environment in the greenhouse by adjusting the light and temperature. Within the shading net and keeping warm quilt are respectively, and the screen aluminum foil shading net according to various shade in the hot summer rate can reflect a part of the sun, and make the sunshine diffuse into the interior, uniform irradiation crops in order to protect the crops from strong light burns, at the same time make the greenhouse temperature drop 3-5 ℃;

The way of rack and pinion driving system, which divides upper and down two layers in a multi-span greenhouse, One system divides 4 areas in total.

Table 1 Inside Shading/Keeping Warm System Specification

NO.	Name	Function	Specification	Note
1	Gear Motor	Placed in the center of each system and near the columns	SBL-WJ80-5.2	Sainpoly
2	Chain	Using for gear motor and driving shaft
3	Rack and pinion	A Type/L=3965mmT=2.75mm		Sainpoly
4	Push rod	Push the curtain	Ф25
5	Push and Guide pipe connector	Using for push rod connection	Ф25
6	Curtain line	Fixing shading net on greenhouse structure	Ф2.0
7	Aluminum profiles	Driving shaft,Aluminum	Rectangle
8	Shading Net	Round wire shading net	75％

Table 2 Gear motor technical parameters

Type	Torque	Driving method	Turning rate	Power	Voltage	Electric current
SBL-WJ80-5.2	800	Gear	5.2	0.75	380	1.5

After-Sales Service

☆ Provide professional installation drawings and installation videos, dedicated to solving customer installation problems
☆ Technician guides the installation on site (Charge)
☆ Provide remote installation guidance services. Realize through video conference or video real-time guidance. (Charge)
☆ Provide real-time installation video for a single span of the greenhouse of the same specification. (Charge)
☆ Visit customers and provide help for customers' greenhouse operation. Find out the problems in the use of the greenhouse in time.
☆ Remote assistance for unloading and inspection
☆ During the warranty period, damaged greenhouse materials, systems, etc., will be replaced free of charge
After the warranty period, provide customers with cost price to replace greenhouse accessories, systems, etc.
☆ Plantation staff training (Charge)
